Bellow Seal Gate Valve , Forged Carbon Steel, Stainless Steel ,
Class 300
PRODUCT INTRODUCTION
1. Gate Valve Product Description
TongJiang bellows seal gate valves feature a formed multi-ply
bellows welded to the stem and to the bottom of the bonnet,
creating a hermetic seal or impermeable barrier. Bellows are
available in many materials for virtually all corrosive chemical
applications.
2. Bellow Seal Gate Valve Technical Data
- Valve Designed to API-602 / BS – 5352 (Reduced Bore)
- Valve Tested to API – 598 / BS – 5146
- Socket Weld End as ANSI-B-16.11
- Screwed End as per ANSI-B1.20.1 (NPT)
- Butt Weld End as per ANSI-B-16.25 with end pups
- End to End as per manufacturers specification
| Size – NB (mm) | 15 | 20 | 25 | 40 |
| Face to Face | 85 | 90 | 110 | 145 |
| Socket Diameter | 21.72 | 27.05 | 33.78 | 48.64 |
| Socket Depth | 09.6 | 12.7 | 12.7 | 12.7 |
NOTES
- Valve upto 40 mm NB are from forging
- Optional Full port Design upto 40 mm NB
- Also Manufactured in ASTM-A 182 Gr. F304L / F316L
- Optional Stellited Seat & Wedge
- Optional Screwed Ends (BSP / NPT)
- Optional Butt Weld Ends
- Alternate Bellow Material : HC-276 / Inconel/625/Monel 400
ACCESSORIES
- Hand Wheel Locking Arrangement
- Extended Stem Design
- Actuator Mounted Valve
3. Bellow Seal Gate Valve Drawing
| Sizes |
| Size | Nomen. | Size | Nomen. |
| 1/8″ | 6 | 8″ | 200 |
| 1/4″ | 8 | 10″ | 250 |
| 3/8″ | 10 | 12″ | 300 |
| 1/2″ | 15 | 14″ | 350 |
| 3/4″ | 20 | 16″ | 400 |
| 1″ | 25 | 18″ | 450 |
| 1 1/4″ | 32 | 20″ | 500 |
| 1 1/2″ | 40 | 22″ | 550 |
| 2″ | 50 | 24″ | 600 |
| 2 1/2″ | 65 | 26″ | 650 |
| 3″ | 80 | 28″ | 700 |
| 4″ | 100 | 30″ | 750 |
| 5″ | 125 | 32″ | 800 |
| 6″ | 150 | 36″ | 900 |
Please feel free to contact with us at angela@tjfmcn.com or filling up an enquiry form instructed at the bottom.
You will get an effective response within 24 hours from TongJiang
Team.
